EZ to Hook Up, No Need to Lift the Lever to Hook it Up. EZ to Latch, The Lever lifts to allow the Coupler Socket to Receive the Hitch Ball. EZ to Use, Once Seated in the Coupler, the Latch Automatically Snaps to its Locked Position.
- Capacity: 10,000 lb
- Fits 2" Ball
- Demco EZ Latch 2" Coupler with composite handle and 4 holes
- Silver Powder Coated Stamped Coupler
- Salt Spray Test: 500 Hours
- Bolt on to 3" Wide Channel
- Mounting Options, which holes to use: Top Three, Front Three or All Four
- Top row of mounting holes: Center to Center between 1st and 2nd - 3"; between 2nd and 3rd -2"
- Bottom mounting hole is 1-1/8" lower than top row and 1.5" back from 1st hole
- Repair Kit: 6109 - EZ Latch - Composite Handle
- Optional Locking safety pins: 5685- Sold Separately
- Optional 5/16" x 3-1/2" safety pin 21987 - Sold Separately
- Patent Number: 76906732
All Demco EZ-Latch couplers are tested and rated without the use of a safety pin and are not required for the couplers to be used in safe operation. A security hole is available on all the EZ-Latch couplers to be used in correlation with a Lock for theft deterrence.
picture_as_pdf Download EZ Latch Instructions
Product Videos
Videos Hide Videos Show Videos
1 Review announcement Hide Reviews Show Reviews
-
Demco Coupler
Way better then the std couples that come with trailers. I bought an Aluma that had one on it, loved it and so bought one for my other trailer. Note: You "open" it like the old kind. Just lower the trailer tongue over the ball and it'll latch itself. (After you pull the lock if you have one.)
